YXMF-700-1100 Hdpe Single Layer Film Blowing Mmachine (Inline-Printing)
Maxmium Film width:
1100MM
Thickness:
0.005mm~0.05mm
Capacity:
20-100kg/hr
Material:
HDPE, LDPE, LLDPE
Size:
700MM-1100MM
End Product:
shopping bag,Express packaging bags...
Product DetailsDownload 2025 New Yuexing Catalogue
Machine width | 700-1100MM | ||||
| Materials | HDPE, LDPE, LLDPE | ||||
| Film thickness | 0.005mm~0.05mm | ||||
| Screw diameter | Φ45 | Φ50 | Φ55 | Φ60 | Φ65 |
| Gearbox | #146 | #173 | #180 | #200 | #200 |
| Main motor | 15kw | 18.5kw | 22kw | 30kw | 37kw |
| Capacity | 20-40kg/h | 30-50kg/h | 30-70kg/h | 40-80kg/h | 50-100kg/h |
Customization Notice: Since every YueXing Blown Film Machine is tailored to specific production needs (ABA/ABC structure, width, output), the final price varies.
Technical Specifications & FAQ
Define output based on your specific film gauge and resin type. Real-world performance depends on maintaining bubble stability at your thinnest target micron. What are the Industry 4.0 requirements for new machines?
Yes, but it requires specific specs. For a 15-150 micron range, you need an adjustable die gap, an 8:1 haul-off speed range, and a flexible air ring. Changeover time usually takes 30-45 minutes. How Adjusting die gap
The extruder screw diameter determines the output capacity (kg/hr), while the die head diameter and Blow-Up Ratio (BUR) determine the film's layflat width. To spec a machine, you should define your target width and thickness first, then work backward to determine the required output and screw size. How do I spec the right extruder size for my target film width?
Since 1999, Yuexing Machinery has been at the forefront of film blowing machine innovation. Our advanced technology and dedication to quality have made us a reliable partner for businesses worldwide. Whether you need single-layer or multi-layer solutions, we are here to meet your needs.
